Outdoor LED Display Screen with Die Cast Aluminum Cabinet Full Color and High Brightness for Advertising
Dettagli:
| Luogo di origine: | Guangdong, Cina |
| Marca: | LEDKING or OEM & ODM |
| Numero di modello: | FO-P5/6.67/8/10 |
Termini di pagamento e spedizione:
| Quantità di ordine minimo: | 1 |
|---|---|
| Prezzo: | $456-476 |
|
Informazioni dettagliate |
|||
| Pixel pitch: | 5 mm, 6 mm, 6,67 mm | Densità dei pixel: | 40000 punti/m2, 27777 punti/m2, 22477 punti/m2 |
|---|---|---|---|
| Configurazione pixel: | 1R1G1B | Consumo massimo di energia: | 40 W, 29 W, 43 W |
| Peso del pannello: | 0,45 kg, 0,35 kg, 0,45 kg | Dimensione del mobile: | 960 mm*960 mm*90 mm, 576 mm*576 mm*90 mm, 768 mm*768 mm*90 mm |
| Risoluzione del gabinetto: | 192 punti * 192 punti, 96 punti * 96 punti, 128 punti*128 punti, 144 punti*144 punti | Migliore angolo di visione: | 170/120, 140/120 |
| Alimentazione elettrica dello schermo: | AC110V/220V - 5V60A | Capacità di potenza massima: | 976 W/m2, 1050 W/m2, 1350 W/m2 |
| Aggiorna frequenza: | 1920-3840 HZ/S | Luminosità: | 5000-5500 mcd/m2, 4000-5000 cd/m2 |
| Distanza di controllo: | <100M | Temperatura operativa: | -10°C~45°C |
| Umidità operativa: | 10-90% | ||
| Evidenziare: | Die Cast Aluminum Cabinet LED Video Wall,Full Color Outdoor LED Display Screen,High Brightness Digital Signage Billboard |
||
Descrizione di prodotto
960×960 P5 P6.67 P8 P10 Fixed Outdoor LED Video Wall Display
Product Specifications
Module Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Panel Dimension | 320mm(W) × 160mm(H) | 192mm(W) × 192mm(H) | 320mm(W) × 160mm(H) |
| Pixel pitch | 5mm | 6mm | 6.67mm |
| Pixel Density | 40000 dot/m² | 27777 dot/m² | 22477 dot/m² |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| Specification | SMD1921 | SMD3535 | SMD3535 |
| Pixel resolution | 64 dot × 32 dot | 32 dot × 32 dot | 48 dot × 48 dot |
| Max power consumption | 40W | 29W | 43W |
| Panel weight | 0.45KG | 0.35KG | 0.45KG |
Cabinet Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Cabinet size | 960mm×960mm×90mm | 576mm×576mm×90mm, 768mm×768mm×90mm | 960mm×960mm×90mm |
| Cabinet Resolution | 192 dot × 192 dot | 96 dot × 96 dot, 128dot×128dot | 144dot×144dot |
| Quantity of panel | 18pcs | 9pcs, 16pcs | 18pcs |
| Hub connecting | HUB75-E | HUB75-E | HUB75-E |
| Cabinet Material | Diecast aluminum cabinet | Diecast aluminum cabinet | Diecast aluminum cabinet |
| Maintenance Method | Front/Back service | Front/Back service | Front/Back service |
| Best viewing angle | 170/120 | 140/120 | 140/120 |
| Screen power supply | AC110V/220V - 5V60A | AC110V/220V - 5V60A | AC110V/220V - 5V60A |
| Max power capacity | 976W/m² | 1050W/m² | 1350W/m² |
| Average power | 488W/m² | 525W/m² | 675W/m² |
Technical Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Driving IC | ICN 2037 / 2153 | ICN 2037 / 2153 | ICN 2037 / 2153 |
| Scan Rate | 1/8S | 1/8S | 1/6S |
| Refresh frequency | 1920-3840 HZ/S | 1920-3840 HZ/S | 1920-3840 HZ/S |
| Display color | 4096×4096×4096 | 4096×4096×4096 | 4096×4096×4096 |
| Brightness | 5000-5500 mcd/m² | 4000-5000 cd/m² | 4000-5000 cd/m² |
| Life span | 100000 Hours | 100000 Hours | 100000 Hours |
| Control distance | < 100M | < 100M | < 100M |
| Best viewing distance | 5-40M | 6-40M | 6-40M |
| Operating temperature | -10°C ~ 45°C | -10°C ~ 45°C | -10°C ~ 45°C |
| Operating Humidity | 10-90% | 10-90% | 10-90% |
| IP protective index | IP65 | IP65 | IP65 |
Most in Kinglight and 3840 refresh rate, if need to change detail
More Pixel Pitch and technical details, feel free to contact us
More Pixel Pitch and technical details, feel free to contact us
